Perspiration Tester
16800 INR
Product Details:
- Response Time Immediate (Manual Operation)
- Hardness Hardened & Polished Stainless Steel Plates
- Specimen Size 10cm x 4cm
- Measuring Range Conforms to ISO, AATCC, BIS standards
- Max Height 150 mm (Frame Size)
- Test Range Perspiration Fastness Testing
- Temperature As Per Required Test Condition
- Click to View more
X
Perspiration Tester Price And Quantity
- 16800 INR
- 01 Piece
- 0.1 mm & 0.3 mm
- Stainless Steel 304 Grade
- Includes Support Plates & Loading Rods
- Easy to Clean and Service
- 115 mm x 60 mm
- Polished
- High
- 220 mm x 180 mm x 150 mm
- 2 (As per Standard Specifications)
Perspiration Tester Product Specifications
- Immediate (Manual Operation)
- 60 mm
- Hardened & Polished Stainless Steel Plates
- 10cm x 4cm
- Conforms to ISO, AATCC, BIS standards
- Standard (Dependent on Manual Operation)
- 150 mm (Frame Size)
- Perspiration Fastness Testing
- As Per Required Test Condition
- Perspiration Tester
- 24 Specimens
- Up to 24 Specimens
- Color Fastness to Perspiration Testing of Textile, Leather, etc.
- Desktop
- Lab Testing Equipment
- Manual
- Not Required (Mechanical)
- Manual
- As Per Test Environment
- 1 Specimen Position
- 10 kg
- Corrosion Resistant, Stainless Steel Construction
- 0.1 mm & 0.3 mm
- Stainless Steel 304 Grade
- Includes Support Plates & Loading Rods
- Easy to Clean and Service
- 115 mm x 60 mm
- Polished
- High
- 220 mm x 180 mm x 150 mm
- 2 (As per Standard Specifications)
Perspiration Tester Trade Information
- Cash Against Delivery (CAD), Cheque, Cash Advance (CA)
- Per Day
- Days
- West India
Product Description
Perspiration Tester -ISO -ITEM CODE: KTS 020
To determine the color fastness to perspiration, against water and sea water of various textiles as per ISO 105.
Specially designed equipment to determine color fastness to water and perspiration as per ISO specification. Total up to 20 specimens can be tested at a time. Stainless steel grade 316 body for durability & long life operation. Special stainless steel springs are provided to compensate the shrinkage of samples.
TECHNICAL DETAILS: Load on the test specimen (as per ISO) : 5 kg(5000 gm) Size of test specimen : 100 x 40 mm Size of acrylic separator plate(each) : 115 x 60 mm Number of separator plates : 21 No.s, Dimension of the Package : 16 (L) x 3(W) x 7(H) inch, Net weight of the unit : 9.7 kg
Supplied ISO TestWeight : 0.47kg(1lb)-with plate and 3.36kg weight in total 5kg(11lb)
Acrylic Plates (Pack of 21)
Standards: ISO 105, BS 106, DIN 54005 / 6 / 7, IS 767 /971,
Required Equipment for Perspiration Fastness Measurement
- Perspiration tester
- Incubator, Maintained at 3+/-2 Deg.
- Multifiber test fabric
- Grey scale
- Color matching chamber
Precision Engineering for Reliable Results
Fabricated entirely from Stainless Steel 304 Grade, this Perspiration Tester maintains high corrosion resistance and a polished finish for longevity and hygienic operation. Its plate and spacer dimensions are meticulously designed to deliver consistent pressure on specimens, resulting in uniform and reliable color fastness testing outcomes for textiles and leathers.
User-Friendly and Maintenance-Free Design
The Perspiration Tester simplifies lab work through manual operation, eliminating the need for a power supply. Its design emphasizes ease of use, quick response, and straightforward specimen placement. Regular cleaning and servicing are effortless, thanks to the plates polished surfaces and solid stainless steel build, ensuring the equipment stays in top condition for repeated use.
Adaptable Testing for Multiple Standards
Engineered to meet a variety of international standards such as ISO, AATCC, and BIS, the tester offers versatile compatibility for industry requirements. Its test range is specifically tailored for evaluating perspiration-induced color change, accurately accommodating 24 specimens at once, making it suitable for high-throughput laboratory settings.
FAQs of Perspiration Tester:
Q: How is the Perspiration Tester used for evaluating color fastness to perspiration?
A: The Perspiration Tester is used by placing pre-treated textile or leather specimens between the stainless steel plates, then applying the required pressure using the included weights and spacers. The assembly is exposed to specified humidity and temperature as per testing standards. This process simulates the effects of perspiration, allowing assessment of color fastness through visual examination.Q: What materials and finishes are utilized in the construction of the Perspiration Tester?
A: The tester is constructed from high-grade Stainless Steel 304 with a polished finish, ensuring excellent corrosion resistance, durability, and easy cleaning. All sample-supporting plates and rods are also stainless steel, providing robust and contamination-free testing conditions.Q: When should laboratories use this Perspiration Tester?
A: This device is ideal whenever laboratories need to verify the color fastness of textiles, leather, or similar specimens to perspiration, as required by ISO, AATCC, or BIS methods. Its essential for routine quality control or during product development stages to ensure compliance with industry standards.Q: Where is the Perspiration Tester typically installed and operated?
A: Designed for desktop use, the Perspiration Tester is commonly placed in textile and leather testing laboratories. Its compact form allows it to fit easily on standard lab benches, providing convenient access for operators.Q: What is the process for preparing samples and conducting a test with this machine?
A: Up to 24 specimens, each cut to 10 cm x 4 cm, are prepared and treated as outlined in the relevant testing standard. Specimens are layered with specified spacers between polished plates, secured using loading rods and weights. The test assembly is then subjected to controlled environmental conditions, after which results are evaluated for color changes.Q: How does the manual operation enhance the usability and durability of the Perspiration Tester?
A: Manual controls eliminate the need for electrical components, reducing maintenance and risk of malfunction. This ensures immediate response and consistent operation, while the stainless steel construction further extends the testers service life, making it reliable for frequent laboratory use.Q: What are the key benefits of using this Perspiration Tester in textile labs?
A: Laboratories benefit from accurate, standardized testing (accommodating up to 24 specimens), robust corrosion-resistant construction, compliance with global standards, straightforward maintenance, and efficient manual operation, delivering consistent, reproducible results for quality control and research purposes.Tell us about your requirement
